120mm Sintetizador de Voz
BKV

El BKV es un anunciador de voz MP3 que produce un sonido de excelente calidad a partir de archivos MP3 pregrabados. El concepto de montaje en panel le da una apariencia bien definida e integrada en la mayoría de las aplicaciones y se programa fácilmente con la tarjeta SD de Patlite (se vende por separado) y el software de programación gratuito de Patlite (que se puede descargar).

  • control de contacto
  • □120
  • Anunciador mp3
  • Voz
  • 95dB
  • Bajo techo/en exteriores
  • IP54
  • 120mm Sintetizador de Voz BKV
  • Sólo disponible en la versión de montaje embutido.
  • Capaz de producir un sonido fuerte de hasta 95dB (a 1m) a pesar de su tamaño compacto.
  • Un control de volumen en el panel delantero proporciona una manera fácil de ajustar el volumen del sonido.
  • El uso de una tarjeta SD permite cambiar los mensajes sin desmontar el dispositivo.
  • Ecológico ya que la unidad cumple con las Directivas RoHS de la Unión Europea.
  • Hay disponibles varios modos de reproducción para distintas aplicaciones.
  • Cuenta con una entrada binaria como opción estándar para seleccionar hasta 31 mensajes.
  • Soporta la selección de entrada con un transistor NPN de colector abierto.
  • La unidad cumple con las directivas de la Unión Europea y cuenta con la certificación CE (sólo BKV-31JF).
  • Disponible en dos colores para que elija el color que mejor vaya con la instalación.
  • Índice de protección: IP54 (sólo la parte delantera cuando se monta al ras).





DIMENSIONES - 120mm x 120mm x 62.8mm
VOLTAJE NOMINAL - DC12/24V
- AC100V
- AC220V
MONTAJE - Montaje en Panel
- Ángulo de montaje vertical solamente
- Interior: Vertical, boca arriba, de lado
- Exterior: Vertical solamente
COLOR DEL CUERPO - Gris Oscuro
- Gris Claro
VOLUMEN - Máximo 95dB a 1 metro
- Control de volumen ajustable
ALMACENAMIENTO DE SONIDO - Tiempo de Grabación Aproximado: 63 segundos (Tasa de bits=64k/s)
SELECCIÓN DE CANAL - Modo de Bits: Seleccione de 1 a 5 canales disponibles con una entrada de señal
- Modo Binario: Seleccione de 1 a 31 canales disponibles con una entrada de señal
NORMAS DE CONFORMIDAD - Marcado CE (Solo BKV-31JF)
- RoHS
- Tecnología de codificación de audio MPEG Layer-3 con licencia de Fraunhofer IIS y Thompson Licensing
CLASIFICACIÓN DE PROTECCIÓN - IP54 (Vertical Solamente)
FUNCIONES - Entrada Momentánea: El mensaje se reproduce una vez
- Entrada Sostenida: El mensaje se repite hasta que la entrada se abre
COMENTARIOS - Cierre de contacto seco como interruptores o contactos de relé
- Transistor de colector abierto (Solo NPN)
OPCIONES - Editor de Listas de Reproducción 2 (Versión de Software Gratuita)
- SDV-2GP: Tarjeta SD (para transferencia y almacenamiento de archivos mp3)

(*) El servicio de descarga de los datos en este sitio se considera que acordó las siguientes condiciones "".

(*) El servicio de descarga de los datos en este sitio se considera que acordó las siguientes condiciones "".

Manual de Instrucciones

Especificaciones del producto

BKV  

BKV  

Piezas de repuesto

Category No. Part Name Part Number Required Qty Specification Approximate time of replacement
Slot Waterproof Cover
C25110015-F1 1

-

-

Terminal Cover
C15140004-F1 2

-

-

Mounting Bracket (2 pieces)
V82100001-F1 2

-

-
